3

Connect Wiring

15

Connect Control Wiring

All low voltage data and option wiring conveniently connects to removable and pluggable

connectors on rear panel of the ERn enclosure.

The rear panel provides removable and pluggable connectors for contact inputs and

outputs, RS-232 serial, Ethernet control, contact closure input and output terminations,

LinkPower, auxiliary power, DMX in, DMX Out, and DMX through.

Rack options such as the redundant rack power supply (ERn-RPS) and the Unison ride thru

option kit terminate to the right I/O board located inside the ERn enclosure.

Connect Rear Panel I/O Data Terminations

Terminate DMX Control Wiring

DMX wire preparation and termination will vary with the type of wire and termination kit

being utilized. Please refer to the instructions supplied with the DMX termination kit for

specifics on the wire preparation.

DMX Input Termination: Screw Terminals Connector

N o t e :

Lance and forms provided as a way to secure wiring with wire ties.

W A R N I N G :

RISK OF DEATH BY ELECTRIC SHOCK! Failure to disconnect all power

before working in the enclosure could result in serious injury or even death.

+

-

+

-

+

-

+

-

+

-

1A
1B
1A
1B
1A
1B
2A
2B
2A
2B
2A
2B

A+ A-

COM

B+B- COM

A+

A- COM

B+B- COM

N

O

4

C

OM

4

N

O

3

C

OM

3

N

O

2

C

OM

2

N

O

1

C

OM

1

I

N

4

G

ND

I

N

3

G

ND

I

N

2

G

ND

I

N

1

G

ND

C

ONTACT

O

UT

C

ONTACT

I

N

DMX A

DMX B

DMX

P

ASS

-T

HRU

L

ON

A

UX

<

<

<

Ethernet

RS-232

serial

1

2

3

4

5

6

7

8

COM

n/c

n/c

n/c

n/c

n/c

Data + (Red)

Data - (Black)

From source

DMX A

If daisy-chaining to
another rack or
DMX device...

This graphic illustrates DMX termination layout for the

screw-terminal connectors that are intended for use

with Belden 9729 cable (or approved equal) cable type.

Screw terminal connectors are supplied as standard in

the DMX Preparation Kit w/ Screw Connector, part

number 4100A1012.

Be aware that cable other than Belden 9729 may have

a different color code for its wire pairs.
