Appendix k, Wiring – Det-Tronics UD10 DCU Emulator FlexVu Universal Display Unit User Manual

Page 53

background image

4.2

95-8656

K-1

AppenDix K

UD10-DCU with C706x TOxIC gaS SENSOR

noTe

For complete information regarding the C7064e H2S Gas Sensor, refer to instruction manual 95-8396.
For the C7067e Chlorine Gas Sensor, refer to instruction manual 95-8439.

WirinG

4000

3500

3000

2500

2000

1500

1000

500

0

18

19

20

21

22

23

24

25

26

27

28

29

30

Power Supply Voltage

Dist

ance in f

t.

UD10-DCU with GT3000/C706X

12
14
16
18

AWG

Wire Size

Notes: Maximum cable length from power source to UD10 is 2000 feet.

Maximum cable length from UD10 to sensor/STB termination box is 2000 feet.
