11 95-8656 4.2
The DCU configuration software supports six detector
types:
Explosive
Oxygen
Universal (Automatic Calibration)
Universal (Manual Calibration)
Pointwatch
Ductwatch
Table 4 shows the recommended settings for each
detector type.
Detector Type Recommended Configuration Comments
GT3000 - All but O2 Universal Automatic
Enter the proper range for the detector. Enter PPM for
units. Then select the alarm and calibration levels.
GT3000 O2 Oxygen
Units and range will automatically be set. Cal level must be
set to 20.9%.
Eclipse Explosive
Proper range and units are automatically set. Alarms are
limited to approval requirements.
Open Path Universal Automatic Enter the proper range and units (LFL-M) for the detector.
PIR9400 Explosive
Proper range and units are automatically set. Alarms are
limited to approval requirements. Calibration gas must be
set to 50%.
C706x Universal Automatic
Enter the proper range for the detector and PPM for units.
Then select the alarm and calibration levels.
505 Explosive
Alarms are limited to approval requirements. Uses %LFL
for units.
NTMOS Universal Automatic
Enter the proper range (0-100) and units (PPM) for the
detector. Calibration gas must be set to 50%.
CGS Explosive
Proper range and units are automatically set. Alarms are
limited to approval requirements. Calibration gas must be
set to 50%.
Generic Universal Automatic
Enter the proper range and units for the detector.
Calibration is not supported, so 50% should be used as
the default.
Table 4—Recommended Settings for each Detector Type
