2-40 3120862
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
103 Bolt, Special Options: 1
0630491 Prior to January 1995
0630474 January 1995 to Present
104 3537903 Plate, Mounting 1
105 0741606 Screw, Flathead 3/8"-16NC x 3/4" 1
106 0721008 Bolt #10-24NC x 1" 2
107 3311005 Locknut #10-24NC 2
108 4751000 Flatwasher #10 4
109 Spacer Options:
4220162 Prior to January 1995
4220111 January 1995 to Present
110 0100011 Loctite #242 A/R
111 4240032 Tie-Strap 1
112 4460234 Clamp 1
113 2820036 Loom (Not Shown) 16 in./41cm
FIGURE 2-13. TURNTABLE AND HOOD INSTALLATION - MODEL 35ELECTRIC. (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
