JLG 45e Parts Manual - Manual (Page 31)

3120862 1-23
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
101 (cont’d) 4844632 35electric Prior to S/N 0300024526
4845262 35electric S/N 0300024526 to Present
4844632 n35electric Prior to S/N 0300023550
4845262 n35electric S/N 0300023550 to Present
4844424 40electric Prior to S/N 0300024233
4845343 40electric S/N 0300024233 to Present
4844424 n40electric Prior to S/N 0300025492
4845343 n40electric S/N 0300025492 to Present
4844424 45electric Prior to S/N 0300024324
4845343 45electric S/N 0300024324 to Present
102 1670696 Cover, Battery Box 2
103 2820063 Insulator, Cover (U/L Machines Only) 2
104 0100065 Adhesive (U/L Machines Only) A/R
105 2940073 Latch 2
106 4565640 Tube 2
107 Hardware Options: A/R
3300029 Wingnut 3/8”-16NC (Not Shown) (30electric) 4
4711500 Flatwasher 5/16" Narrow (35electric/40electric/
45electric) 8
108 Hardware Options: A/R
0630453 Bolt (30electric) 4
0641512 Bolt (35electric/40electric/45electric) 4
109 Liner, Box Options: 2
3000003 30electric/40electric/45electric
3000004 35electric (Prior to S/N 0300044788)
3000003 35electric (S/N 0300044788 to Present)
110 Battery Options: 8
0400069 Wet (30electric)
0400112 Dry (30electric)
0400121 Wet (35electric)
0400136 Dry (35electric)
0400055 Wet (40electric/45electric)
0400107 Dry (40electric/45electric)
111 1060405 Cable, Battery 2
112 1060092 Cable, Battery 6
113 0100048 Silicon Compound A/R
114 0100051 Grease, Terminal A/R
115 1060492 Lanyard 4
116 0630407 Screw, Button Head 1/4" x 5/8" 8
117 3311405 Locknut 1/4"-20NC 8
118 0840031 Boot, Terminal - “d” shape 12
119 0840032 Boot, Terminal - “b” shape 4
120 Hardware Options: 2
2540016 Grommet (U/L Machines)
3520054 Plug (Non U/L Machines)
121 3760170 Ring 2
122 1060491 Cable, Lanyard 2
123 1320172 Handle, Pull 2
124 4300107 Stud 1/2"-16NC x 2" 4
125 4751800 Flatwasher 1/2" 8
FIGURE 1-7. ELECTRICAL COMPONENTS INSTALLATION (FRAME MOUNTED) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
