3120862 7-33
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
1104 Platform Options Harness Options: 1
Not Available Prior to S/N 36648
4922078 S/N 36648 to Present
Above Elevation Tilt Alarm
Above Elevation Tilt Alarm & Drive Cutout
Above Elevation Drive Cutout
Eight Meter Drive Cutout
Overload with Override (Switch at Slave Cyl)
Overload without Override (Switch at Slave Cyl)
1105 Overload Switch Harness/Components 1
Harness Options: 1
1105A Not Available Pressure Switch Located Under Basket (35/40/
45electric)
1060016 Cable, Electrical - 16/3 6ft/1.8m
1105B 4921521 Pressure Switch Located at Slave Cylinder
1105B 4921601 Pressure Switch Located at Slave Cylinder
1105C 4460476 Receptacle, Female - 3 Position 1
4460475 Pin 3
Pressure Switch Options: 1
1105D 4360451 Pressure Switch Located Under Basket
1105E 4360344 Pressure Switch Located at Slave Cylinder
1105F 4460428 Connector, Strain Relief 1
1106 Low Voltage Interrupt/Cutout Harness (Not Shown) A/R
4921566 30electric Harness
4460489 Connector (At Low Voltage Cutout Relay) 1
35/40/45electric Harness Options:
4921983 Harness (Lift Interrupt to MTB) 1
4921984 Harness (Lift Interrupt to Rear Axle) 1
1107 Not Available Platform Proximity Switch Harness (35/40/45 A/R
electric) (Not Shown - Use individual wires)
TOOLS Ref.
1201 7002821 Crimper (For Wire to Pin/Socket Connections) 1
1202 7002823 Extractor (For Removal of Pin/Socket from Connec-
tors) 1
1203 4460467 Extractor, Pin (Blue 16-18 Gauge) (For Removal of
Pin/Socket from Connectors) 1
4460510 Extractor, Pin (Yellow 12-14 Gauge) (For Removal of
Pin/Socket from Connectors) 1
1204 7002828 Stripper, Wire 1
FIGURE 7-7. HARNESS COMPONENTS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
