SECTION 1 FRAME
FIGURE 1-4. DRIVE BRAKE ASSEMBLY
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0920090
DRIVE BRAKE ASSEMBLY
Ref.
B
1
7012552
Magnet and Coil Assembly
1
2
7012582
Armature
1
3
7012554
Shaft
1
4
Not Available
Plate, Mounting
1
5
Kit
Plate, Friction (Solid)
3
6
Not Used
7
Kit
Plate, Outer
2
8
7012692
Spacer
3
9
7014116
Bolt, Metric Socket Head
3
10
Kit
Spring, Compression
8
11
7026609
Bearing, Ball
1
12
7014129
Ring, Retainer (External)
1
13
7014130
Ring, Retainer (Internal)
1
14
7012689
Manual Release Assembly
3
15 to 18
Not Used
19
3790240
O-Ring
1
20
7012691
Shim
A/R
21
7012580
Connector, Electrical
1
7014127
Plug, Base
1
22
3790225
O-Ring (January 1995 to Present)
1
23
7014128
Seal (S/N 50521 to Present)
1
— — — — — — — — — —
7012583
Repair Kit (Includes Items 5,7,10,11 & 22)
1
