SECTION 5 CYLINDER
FIGURE 5-6. PLATFORM ROTATOR CYLINDER ASSEMBLY - MODELS 35ELECTRIC, 40ELECTRIC
AND 45ELECTRIC
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1682930 PLATFORM ROTATOR CYLINDER ASSEMBLY - Ref. B
MODELS 35electric, 40electric AND 45electric
1 7001609 Nut, Hex 1
2 7001610 Piston 1
3 Kit Seal 1
4 Kit O-Ring 1
5 7001611 Barrel Weldment 1
6 7001612 Rod 1
7 7001613 Head 1
8 Kit O-Ring 1
9 Kit Ring, Back-up 1
10 Kit Seal 1
11 Kit Wiper 1
12 7001614 Ring, Retainer 1
— — — — — — — — — —
7001608 Seal Kit - 1682930 Cylinder (Includes Items 3,4 & 8-11) 1
