3120862 1-17
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-5. DRIVE HUB ASSEMBLY - MODEL 30ELECTRIC
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
2780185 DRIVE HUB ASSEMBLY - MODEL 30ELECTRIC Ref. B
Hub-Shaft Assembly 1
1 7010463 Spindle 1
2 7000228 Seal, Lip (Part of Seal Kit) 1
3 7000255 Cup, Bearing (Outer) 1
4 7000256 Cone, Bearing (Outer) 1
5 7000257 Cup, Bearing (Inner) 1
6 7000258 Cone, Bearing (Inner) 1
7 7000259 Housing 1
8 7000232 Thrustwasher (Part of Seal Kit) 1
9 7000229 Ring, Retaining (Part of Seal Kit) 1
10 7000242 Plug, Pipe - 1/4" NPTF 2
11 7000241 Stud, Wheel 1/2"-20NF 9
12 7001952 Plug, Pipe 3/4" NPTF 1
13 7000246 Gear, Internal 1
— — — — — — — — — —
Carrier Assembly 1
14 7001931 Carrier 1
15 7001985 Thrustwasher, Tanged 6
16 7001909 Bearing, Needle 96
17 7000263 Spacer, Thrust 3
18 7001911 Shaft, Planet 3
19 7001912 Gear, Cluster 3
20 7001913 Rollpin 3
21 7000248 Gear, Ring 1
22 7000230 O-Ring (Part of Seal Kit) 2
23 7000209 Cover, Input 1
24 7010461 Gear, Sun 1
25 7000269 Spacer, Input 1
26 7000270 Thrustwasher 1
27 7000253 Thrustwasher (Part of Seal Kit) 2
28 7000217 Bolt, Hex 8
29 7000214 Bolt, Shoulder 4
30 7000242 Plug, Pipe 1/4" NPTF 1
— — — — — — — — — —
2900034 Seal Kit (Includes Items 2,8,9 and 22) 1
2900661 Seal Kit (Includes Items 2,9 22 and 27) 1
