JLG 45e Parts Manual User Manual
Page 60

2-12
3120862
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
112
4460499
Connector, Electrical
8
113
7012912
Cartridge, Relief Valve (Lower Lift)
1
114
7017433
Cartridge, Solenoid Valve (Swing)
1
7010538
Coil (2 Per Assembly)
2
— — — — — — — — —
7012901
Seal Kit (For Item 101)
1
7012998
Seal Kit (For Items 102, 103 and 113)
7010543
Seal Kit (For Items 104)
2
7017402
Seal Kit (For Items 105)
2
7012903
Seal Kit (For Items 106)
2
7012907
Seal Kit (For Items 107)
2
7012918
Seal Kit (For Item 109)
2
7012518
Seal Kit (For Item 110)
1
7017403
Weatherproofing Kit (For Items 106)
2
7017435
Weatherproofing Kit (For Items 107)
2
7012951
Weatherproofing Kit (For Items 105 and 114)
4
4640843
CONTROL VALVE ASSEMBLY - MODEL 35electric
(PRIOR TO S/N 34056)
Ref.
—
201
Not Required
202
7010540
Cartridge, Flow Control Valve (Upper Lift and Swing)
2
203
7012912
Cartridge, Relief Valve (Platform Level & Telescope)
3
204
7010542
Cartridge, Shuttle Valve (Swing)
2
205
7010546
Cartridge, Solenoid Valve (Platform Level and Swing)
1
7010538
Coil (2 Per Assembly)
2
206
7010546
Cartridge, Solenoid Valve
2
7010538
Coil (2 Per Assembly)
4
207
7012946
Cartridge, Solenoid Valve
2
7010538
Coil (1 Per Assembly)
2
208
Not Used
209
7012914
Cartridge, Check Valve (Platform Level)
2
210
Not Required
211
Not Required
212
4460499
Connector, Electrical
8
213
7010540
Cartridge, Relief Valve (Lower Lift)
1
214
7010546
Cartridge, Solenoid Valve (Swing)
1
7010538
Coil (2 Per Assembly)
2
— — — — — — — — — —
7010541
Seal Kit (For Items 202, 203 and 213)
6
7010543
Seal Kit (For Items 204 and 207)
4
7012918
Seal Kit (For Item 209)
2
7010539
Seal Kit (For Items 205,206 and 214)
4
7012951
Weatherproofing Kit (For Items 205, 206, 207 and
214)
6
FIGURE 2-4. CONTROL VALVE ASSEMBLY - MODELS 35ELECTRIC, 40ELECTRIC, AND
45ELECTRIC. (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
