SECTION 5 CYLINDER
FIGURE 5-8. STEER CYLINDER ASSEMBLIES
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
STEER CYLINDER ASSEMBLIES
1682527 35electric/40electric/45electric (Prior to S/N37950) Ref. C/5
1683695 35electric/40electric/45electric (S/N37950 to Pres-
ent)
Ref.
A/2
1682893 n35electric/n40electric (Prior to S/N37950) Ref. B/3
1683696 n35electric/n40electric (S/N37950 to Present) Ref. A/2
1 Barrel Weldment Options: 1
1682528 1682527 & 1682893 Cyls (Prior to S/N37950)
1683694 1683695 & 1683696 Cyls (S/N37950 to Present)
2 Rod Weldment Options: 1
1682530 35electric/40electric/45electric
1682894 n35electric/n40electric
3 3480153 Piston 1
4 1682364 Head 2
5 1120387 Retainer 2
6 4565275 Spacer 2
7 3760141 Ring, Retaining 2
8 Kit Seal, Wiper 2
9 Kit Seal, Rod 2
10 Kit O-Ring 2
11 Kit Ring, Wear 2
12 Kit T-Seal 1
13 Kit O-Ring 1
14 Follower, Cam Options: 1
3860054 Prior to S/N 31331 1
3860076 S/N 31331 to S/N 37950 1
3860080 S/N 37950 to Present 1
15 3321802 Nut, Jam 1/2"-20NF 1
16 0100035 Loctite #222 A/R
17 Not Used
18 2220472 Fitting, 90° 1
19 2220515 Fitting, Cap 2
20 2180699 Fitting, Modified 1
21 2180394 Orifice 1
— — — — — — — — — —
2901178 Seal Kit (Includes Items 8-13) 1
