3120862 5-11
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
SECTION 5 CYLINDER
FIGURE 5-3. MID LIFT CYLINDER ASSEMBLIES - MODELS 40ELECTRIC AND 45ELECTRIC
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
MID LIFT CYLINDER ASSEMBLY
1683018 45electric (Prior to S/N 33090) Ref. D/4
1683522 45electric (S/N 33090 to Present) Ref. A/1
1682861 40electric (Prior to S/N 33111) Ref. C/3
1683519 40electric (S/N 33111 to Present) Ref. A/1
1 Barrel Weldment Options: 1
45electric
1683019 1683018 Cylinder (Prior to S/N33090)
1683516 1683522 Cylinder (S/N33090 to Present)
40electric
1682862 1682861 Cylinder (Prior to S/N 33111)
1683513 1683519 Cylinder (S/N 33111 to Present)
0961726 Bushing, Teflon 2
2 Rod Weldment Options: 1
1683021 45electric
1682864 40electric
0961726 Bushing, Teflon 2
3 Retainer Options: 1
1120305 45electric
1120108 40electric
4 Piston Options: 1
3480113 45electric
3480115 40electric
5 Head Options: 1
1682209 45electric
1681344 40electric
6 Nut, Hex Options: 1
3300281 45electric
3300279 40electric
7 Washer Options: 1
4740207 45electric
4740394 40electric
8 Spacer Options: 1
4566435 45electric
4565994 40electric
9 4640634 Cartridge, Holding Valve 1
2900770 Seal Kit - 4640634 1
10 4640816 Cartridge, Holding Valve 1
2900770 Seal Kit - 4640771 Valve 1
11 2220885 Plug 2
12 3900170 Setscrew 3/8"-16NC x 3/8" 1
13 Setscrew 1/4"-20NC x 1/4" Options: 1
Not Required 45electric
3951402 40electric
14 Kit Ring, Lock 2
15 Kit Seal, Piston 2
16 Kit O-Ring 1
