JLG 45e Parts Manual - Manual (Page 27)

3120862 1-19
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-6. DRIVE HUB ASSEMBLY - MODELS 35ELECTRIC, 40ELECTRIC, 45ELECTRIC
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
2780198 DRIVE HUB ASSEMBLY - MODEL 35ELECTRIC,
40ELECTRIC AND 45ELECTRIC Ref. B
2780198 DRIVE HUB ASSEMBLY - MODEL N35ELECTRIC AND
N40ELECTRIC BUILT PRIOR TO OCTOBER 1994 Ref. B
2780206 DRIVE HUB ASSEMBLY - MODEL N35ELECTRIC AND
N40ELECTRIC BUILT OCTOBER 1994 TO PRESENT Ref. —
Hub-Shaft Assembly 1
1 7010486 Spindle 1
2 7000228 Seal, Lip (Part of Seal Kit) 1
3 7000255 Cup, Bearing (Outer) 1
4 7000256 Cone, Bearing (Outer) 1
5 7000257 Cup, Bearing (Inner) 1
6 7000258 Cone, Bearing (Inner) 1
7 7000259 Housing 1
8 7000232 Thrustwasher (Part of Seal Kit) 1
9 7000229 Ring, Retaining (Part of Seal Kit) 1
10 7000242 Plug, Pipe - 1/4" NPTF 2
11 7000241 Stud, Wheel 1/2"-20NF 9
12 7001952 Plug, Pipe 3/4" NPTF 1
13 7000246 Gear, Internal (2780198) 1
7010491 Gear, Internal (2780206) 1
— — — — — — — — — —
Carrier Assembly 1
14 7010481 Carrier (2780198) 1
7010489 Carrier (2780206) 1
15 7001985 Washer, Tanged Thrust 6
16 7001909 Bearing, Needle 96
17 7000263 Spacer, Thrust 3
18 7010483 Shaft, Planet 3
19 7010484 Gear, Cluster (2780198 Hub) 3
7010490 Gear, Cluster (2780206 Hub) 3
20 7010474 Rollpin 3
21 7000248 Gear, Ring 1
22 7000230 O-Ring (Part of Seal Kit) 2
23 7000209 Cover, Input 1
24 7010482 Gear, Sun 1
25 7010485 Spacer, Input 1
26 7007642 Thrustwasher 1
27 7000253 Thrustwasher (Part of Seal Kit) 2
28 7001923 Bolt, Hex (2780198) 8
7000217 Bolt, Hex (2780206) 8
29 7000214 Bolt, Shoulder 4
30 7000242 Plug, Pipe 1/4" NPTF 1
— — — — — — — — — —
2900034 Seal Kit (Includes Items 2,8,9 and 22) 1
2900661 Seal Kit (Includes Items 2,9 22 and 27) 1
