2-28
3120862
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
102
4360346
Switch, Master Key (Select) (Prior to S/N 47045)
1
7012587
Key, Replacement
1
4360474
Switch, Master Key (Select) - Euro Spec (S/N 47045
to Present)
1
2860030
Key, Replacement
1
4360473
Switch, Master Key (Select) - Australian Spec (S/N
47045 to Present)
1
2860030
Key, Replacement
1
103
4360289
Switch, Emergency Stop (Prior to S/N 47045)
1
7012611
Head, Mushroom
1
7012612
Boot
1
4360475
Switch, Emergency Stop (S/N 47045 to Present)
1
7020175
Cap/E-Stop With Sealing Ring
1
7020176
Contact Block With Mount Collar
1
104
2420106
Meter, Battery Capacity
1
105
4360314
Switch, Toggle
3
106
4060802
Shield, Toggle Switch
3
107
4740397
Washer, Spacer
3
108
4460234
Mount, Cable Tie (Located on Back of Nameplate)
3
109
4420037
Tape, Insulation
4 ft./1.2m
110
Not Used
111
Decal - EMS Options:
1
1704260
Euro Spec (S/N 47045 to Present)
Not Required
Australian Spec
112
4070987
Shim,.015 (S/N 47045 to Present)
1
113
4070991
Shim,.125 (S/N 47045 to Present)
1
114
3910804
Screw #8-32NC x 1/4” (S/N 47045 to Present)
6
TERMINAL STRIP ASSEMBLY
4460545
Euro Spec
Ref.
—
4460545
Australian Spec Prior to S/N 36574
Ref.
—
4460735
Australian Spec S/N 36574 to Present
Ref.
2/A
201
3640930
Rail
A/R
202
4460299
Stop, Terminal
A/R
203
4460298
Block, Terminal
12
204
0610107
Card, Circuit
1
205
4460300
Barrier, Terminal
2
206
4460308
Bar, Buss - 2 Position
1
207
4460310
Bar, Buss - 4 Position
1
208
4460305
Screw
6
209
4460306
Washer
6
210
4460307
Sleeve
6
211
4460301
Strip, Marking
2
212
Not Used
213
3740087
Relay - 48VDC (Not Shown - Australian Spec S/N
36374 to Present Only)
1
214
4120027
Relay, Socket (Not Shown - Australian Spec S/N
36374 to Present Only)
1
FIGURE 2-10. GROUND CONTROL COMPONENTS INSTALLATIONS - MODEL 30ELECTRIC.
