JLG 45e Parts Manual User Manual
Page 126
4-14
3120862
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
12
2920107
Bulb
1
13
4360274
Switch, Push Button (Horn)
1
14
1600175
Controller Assembly (Drive/Steer) (See Figure 4-5 for
Breakdown)
1
15
0720805
Screw, Machine #8-32NC x 5/8"
4
16
4750800
Flatwasher #8
4
17
4760800
Lockwasher #8
4
18
3537234
Plate, Controller Support
1
19
3520031
Plug, Hole
1
20
4460488
Mount, Cable Tie
4
21
3640834
Strip, Terminal
A/R
22
3910608
Screw #6-32NC x 1 1/2"
4
23
4760600
Lockwasher #6
4
24
4750600
Flatwasher #6
4
25
3310601
Nut #6-32NC
4
26
3740087
Relay
A/R
27
4120027
Base, Relay
A/R
28
3740063
Spring, Relay
A/R
29
4460522
Block, Terminal
3
30
4460525
Markers, Terminal
1
31
4460524
Lock, Terminal
3
32
4460526
Connector, Strain Relief
1
33
4460428
Connector, Strain Relief
A/R
34
0641508
Bolt 5/16"-18NC x 1"
4
35
4751500
Flatwasher 5/16"
4
36
4761500
Lockwasher 5/16"
4
37
Not Used
38
4360112
Breaker, Circuit - 5 Amp
2
39
Breaker, Circuit - 10 Amp
A/R
Not Required
30electric
0
4360069
35electric/40electric/45electric 1
40
4740420
Washer, Sealing
6
41
3640930
Rail
1
42
0100029
Silicone
A/R
43
3790012
O-Ring
3
44
1060329
Lanyard
1
45
0731003
Bolt #10-24NC x 3/8"
1
46
4751000
Flatwasher #10
1
47
4761000
Lockwasher #10
1
48
Plug, Terminal Options:
A/R
Not Required
30electric
0
4460523
35electric/40electric/45electric 1
49
Bridge, Insertion Options:
A/R
Not Required
30electric
0
4460529
35electric/40electric/45electric 2
50
1704260
Decal - EMS (S/N 47045 to Present)
1
FIGURE 4-4. PLATFORM CONSOLE ASSEMBLY (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
