Page 33
3120862
1-25
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
301 cont’d
0400137
220V/50Hz Dutch/French/German/Italian/Spanish
Specs (August 1995 to S/N 03000 63149)
0400130
250V/50Hz Australian Specs
0400111
110-220V/50Hz UK Spec (Prior to
S/N 0300036625)
0400182
110-220V/50Hz UK Spec (S/N 0300036625 to
Present)
0400198
110-240V/50Hz CE Spec (S/N 03000 63149 to
Present)
302
0641408
Bolt 1/4"-20NC x 1"
2
303
4711400
Flatwasher 1/4" Narrow
2
304
3311405
Locknut 1/4"-20NC
2
305
4761400
Lockwasher 1/4"
2
306
0641408
Bolt 1/4"-20NC x 1"
2
307
Instructions Decal Options (Not Shown):
1
1701695
110V English Language
1702352
220V English Language
1702950
110V Spanish Language
1702949
220V Spanish Language
308
3300181
Nut, Retainer 1/4"-20NC
2
0255642
CHASSIS GROUND INSTALLATION (NOT SHOWN)
Ref.
—
1060080
Cable, Battery
1
4791500
Starwasher 5/16”
1
0840041
Boot, Terminal
1
FIGURE 1-7. ELECTRICAL COMPONENTS INSTALLATION (FRAME MOUNTED) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
