7-26 3120862
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-7. HARNESS COMPONENTS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
ELECTRICAL HARNESS AND COMPONENTS
INSTALLATION Ref.
NOTE: NUMBERED COLORED WIRE STARTS WITH
S/N 36648
NOTE: FOR ALL BATTERY AND CONTACTOR
CABLES SEE SECTION 1.
PLATFORM CONSOLE BOX COMPONENTS Ref.
1 to 31 Not Used
32 4460526 Connector, Strain Relief 1
33 4460428 Connector, Strain Relief A/R
34 to 47 Not Used
48 Plug, Terminal Options: A/R
Not Required 30electric 0
4460523 35electric/40electric/45electric 1
49 Bridge, Insertion A/R
Not Required 30electric 0
4460529 35electric/40electric/45electric 2
PLATFORM ELECTRICAL DIAGRAMS
4932674 30electricPrior to S/N 33441 Ref. A
4932936 30electricS/N 33441 to S/N36544 Ref. —
4933002 30electricS/N 36544 to Present Ref. 2/B
4932659 35/40/45electricPrior to S/N 33441 Ref. C
4932937 35/40/45electricS/N 33441 to S/N36648 Ref. —
4932988 35/40/45electricS/N 36648 to Present Ref. 2/B
101 Harness, Platform Console Box Options: 1
Not Available 30electric Prior to S/N 36544
4922056 30electric S/N 36544 to Present
Not Available 35/40/45electric Prior to S/N 36648
4922042 35/40/45electric S/N 36648 to Present
102 3990001 Diode - 3.5 Amp (Not Shown) 2
103 1060341 Cable, Electrical - 16/2 (35/40/45electric only) 8 ft./2.4m
104 1060330 Cable, Electrical - 16/3 7 ft./2.2m
105 to 109 Not Used
110 3990010 Diode - 6 Amp (Not Shown) 1
BOOM CABLES INSTALLATIONS
0254738 30electric Euro & Australian Spec Prior to S/N 36544 Ref. A
0258226 30electric Euro Spec S/N 36544 to Present Ref. 1
0258345 30electric Australian Spec S/N 36544 to Present Ref. 1
0254595 35electric Prior to S/N 36648 Ref. D
0258565 35electric S/N 36648 to Present Ref. 1
0254647 40electric Prior to S/N 36648 Ref. 6
0258563 40electric S/N 36648 to Present Ref. 1
0254041 45electric Prior to S/N 36648 Ref. 7
0258564 45electric S/N 36648 to Present Ref. 1
