JLG 45e Parts Manual User Manual
Page 37

3120862
1-29
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
114
7011508
Fuse, AC - 15 Amp
1
115
7011507
Holder, Fuse - AC
1
116
Not Available
Handle
2
117
7011621
Connector, Enable Switch
1
118
Not Available
Heatsink
1
119
7011511
Strap, Condenser
1
120
Automatic Switching Card Options:
1
7011644
Prior to Date Code BT (February 1996) (Use
7018504 Kit as Replacement)
7018530
Date Code BT (February 1996 to Present)
121
7011649
Relay
1
— — — — — — — — — —
7018504
Circuit Isolation Kit (Modification required for
chargers built prior to date code “BT”)
1
FIGURE 1-8. BATTERY CHARGER ASSEMBLY - 220V/50HZ (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
