SECTION 1 FRAME
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0400198
BATTERY CHARGER ASSEMBLY - DUTCH/ FRENCH/
GERMAN/ITALIAN/SPANISH SPECS (SERVICE
REPLACEMENT FOR 0400103 & 0400137 BATTERY
CHARGERS)
Ref.
—
1
Use 7011573
Ammeter (was p/n 7022915)
1
2
7022904
Cover Assembly, Case
1
3
7018525
Breaker, Circuit
1
4
7022938
Board, Circuit (was p/n 7022934)
1
5
7011621
Connector
1
6
7022914
Cord, AC
1
7
7022916
Cord, DC
1
8
7018577
Capacitor Assembly (Not Shown)
2
9
7011593
Fuse, DC - 45 Amp
1
10
7020658
Harness (Not Shown)
1
11
7011594
Holder, Fuse - DC
1
12
7011590
Connector, DC
1
13
7020649
Recifier Assembly
2
14
7020650
Recifier (1 Per Assembly)
1
15
7018563
Relay
1
16
7020674
Shunt Assembly
1
17
7011529
Strain Relief
1
7020659
Strain Relief
1
18
Use 7022939
Transformer (was p/n 7022917)
1
19
7020633
Varistor Assembly
1
