SECTION 4 PLATFORMS
309
Supply Locally
Gasket
1
310
Harness Options (Lower Boom):
1
4921648
35electric
4921570
40electric
4921594
45electric
310A
4460134
Receptacle
1
OPTIONAL WORK LIGHTS KITS
2901251
Prior to S/N 36544
Ref.
E
2901561
S/N 36544 to Present
Ref.
2
401
3536089
Plate, Mounting
2
402
0641414
Bolt 1/4"-20NC x 1 3/4"
4
403
3311405
Locknut 1/4"-20NC
4
404
4711400
Flatwasher 1/4" Narrow
4
405
2920095
Floodlight
2
7016356
Bulb, Replacement (1per Light)
2
406
4240099
Tie-Strap
10
407 to 408
Not Used
409
2820035
Loom, Vinyl (Not Shown)
9 ft./2.7m
410
Not Used
411
Connector, Strain Relief Options (Not Shown -
Located at Console Box):
1
4460598
Prior to S/N 28755
4460428
S/N 28755 to Present
2901213
OPTIONAL CONSOLE COVER KIT - STANDARD
MACHINES
Ref.
—
501
1670636
Cover
1
FIGURE 4-2. PLATFORM AND COMPONENTS INSTALLATION - MODEL 35ELECTRIC, 40ELECTRIC
AND 45ELECTRIC (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
