SECTION 1 FRAME
HUBCAP INSTALLATION (OPTIONAL) Ref.
0252754 Use on Model 30electric Ref. B
0253864 Use on Model 35electric/40electric with 8" Rim/
Pneumatic and 8" Rim/ Foam-Filled Tires. Use on
Model 45electric with 8" Rim /Foam-Filled Tires. Ref. B
0256832 Use on Model 35electric/40electric/45electric
with. 6” Rim. Ref. —
0254155 Use on Model 35electric and 40electric with Solid
Tires. Ref. B
201 Hubcap Options: 4
1670633 Model 30electric
1670633 Model 35electric/40electric with 8" Rim/ Pneu-
matic and 8" Rim/ Foam-Filled Tires. Use on
Model 45electric with 8" Rim /Foam-Filled Tires.
1670808 Model 35electric/40electric/45electric with. 6”
Rim
1670692 Model 35electric and 40electric with Solid Tires.
202 Bolt Options: 8
0630455 J-Bolt 5/16"-18NC - Model 30electric
0630465 J-Bolt 5/16"-18NC - Model 35electric/40electric
with 8" Rim/ Pneumatic and 8” Rim/Foam-Filled
Tires. use on Model 45electric with 8” Rim/
Foam-Filled Tires.
0630513 J-Bolt 5/16"-18NC - Model 35electric/40electric/
45electric with 6” Rims
0641518
Bolt 5/16"-18NC x 2 1/4" - Model 35electric and
40electric with Solid Tires
203 4761500 Lockwasher 5/16" 8
204 Nut, Acorn 5/16"-18NC Options: 8
3300356 Model 30electric
3300356 Model 35electric/40electric with 8" Rim/ Pneu-
matic and 8” Rim/Foam-Filled Tires. use on
Model 45electric with 8” Rim/Foam-Filled Tires.
3300356 Model 35electric/40electric/45electric with 6”
Rims
Not Required Model 35electric and 40electric with Solid Tires
205 Nut 5/16"-18NC Options: 8
3311501 Model 30electric
3311501 Model 35electric/40electric with 8" Rim/ Pneu-
matic and 8” Rim/Foam-Filled Tires. use on
Model 45electric with 8” Rim/Foam-Filled Tires.
3311501 Model 35electric/40electric/45electric with 6”
Rims
Not Required Model 35electric and 40electric with Solid Tires
FIGURE 1-3. TIRE AND WHEEL DRIVE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
