2-8
3120862
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
ALARM KITS
2901249
Motion Alarm Kit Prior to S/N 0300036648 without
Numbered Colored Wire
Ref.
2
2901601
Motion Alarm Kit S/N 0300036648 to Present with
Numbered Colored Wire
Ref.
1
201
0140031
Alarm, Motion (Remove ground strap before installa-
tion)
1
202
3311405
Locknut 1/4"-20NC
2
203
4711400
Flatwasher 1/4" Thin
4
204
Harness Options (Not Shown):
1
4921425
Prior to S/N 0300036648 w/o Numbered Colored
Wire
4922076
S/N 0300036648 to Present with Numbered
Colored Wire
0255522
MANUAL ASCENT COMPONENTS INSTALLATION
(DUTCH SPEC ONLY)
Ref.
2
301
2752478
Hose (To Ports “P” & “T1”)
2
2220603
Fitting, Straight
4
2220775
Fitting, 90°
1
2752461
Hose (To Port “T2”)
1
2220606
Fitting, Tee
1
4640933
Valve Assembly
1
7012686
Valve, Rexroth
1
7012687
Valve, Cartridge
1
7012953
Seal Kit - 7012687 Valve
1
0641514
Bolt 5/16”-18NC x 1 3/4”
2
4751500
Flatwasher 5/16” Regular
2
4761500
Lockwasher 5/16”
2
1702545
Decal - Manual Ascent
2
FIGURE 2-3. TURNTABLE MOUNTED COMPONENTS INSTALLATIONS - MODEL 40ELECTRIC AND
45ELECTRIC. (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
