4-4 3120862
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
OPTIONAL WORK LIGHTS KITS
2901251 Prior to S/N 36544 Ref. E
2901561 S/N 36544 to Present Ref. 2
501 3536089 Plate, Mounting 2
502 0641414 Bolt 1/4"-20NC x 1 3/4" 4
503 3311405 Locknut 1/4"-20NC 4
504 4711400 Flatwasher 1/4" Narrow 4
505 2920095 Light Assembly 2
7016356 Bulb, Replacement (1 per Light) 2
506 4240099 Tie-Strap (Not Shown) 10
507 to 510 Not Used
511 Connector, Strain Relief Options (Not Shown - 1
Located at Console Box):
4460598 Prior to S/N 28755
4460428 S/N 28755 to Present
FIGURE 4-1. PLATFORM AND COMPONENTS INSTALLATION - MODEL 30ELECTRIC
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
