3-20 3120862
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
26 Holder, Wear Pad Options (Base Front Left Side): 1
Use 1220038 Prior to S/N 35014 (was p/n 4844383) 2
1220038 S/N 35014 to Present 2
27 Holder, Wear Pad Options (Base Front Right Side): 1
Use 1220039 Prior to S/N 35014 (was p/n 4844384) 2
1220039 S/N 35014 to Present 2
28 Holder, Wear Pad Options (Base Front Top): 1
Use 1220040 Prior to S/N 35014 (was p/n 4844386) 2
1220040 S/N 35014 to Present 2
29 0630399 Bolt 3/8"-16NC x 2 1/4" 2
30 0100009 Silicone (Not Shown) A/R
31 4740413 Spacer 5
32 4751600 Flatwasher 3/8" 5
33 0641608 Bolt 3/8"-16NC x 1" 5
34 3520034 Plug, Hole 4
35 1320195 Cover, Clamp (March 1995 to Present Only) 1
36 1320199 Clamp (March 1995 to Present Only) 1
37 0641520 Bolt 5/16"-18NC x 2 1/4" (March 1995 to Present)
Only) 1
38 3311505 Locknut 5/16"-18NC (March 1995 to Present Only) 1
FIGURE 3-5. UPPER BOOM COMPONENTS ASSEMBLY - MODELS 35ELECTRIC, 40ELECTRIC
AND 45ELECTRIC (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
