7-30 3120862
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
GROUND CONTROL BOX ELECTRICAL DIAGRAMS
4932675 30electric Euro & Australian Spec Prior to S/N
36544 Ref. A
4933003 30electric Euro Spec S/N 36544 to Present Ref. C/2
4933024 30electric Australian Spec S/N 36544 to Present Ref. 1/C
4932660 35/40/45electric Euro & Australian Spec Prior to
S/N 36648 Ref. H
4932987 35/40/45electric Euro Spec S/N 36648 to Present Ref. 2/C
4933028 35/40/45electric Australian Spec S/N 36648 to
Present Ref. 1/B
701 Harness - Ground Control Box Options: 1
Not Available 30electric Prior to S/N 36544 (Used individual
wires and components)
4922045 30electric Euro Spec S/N 36544 to Present
4922122 30electric Australian Spec S/N 36544 to Present
Not Available 35/40/45electric Prior to S/N 36648 (Used indi-
vidual wires and components)
4922043 35/40/45electric Euro & Australian Spec S/N
36648 to Present
701B 4460419 Terminal 36
701C 3990010 Diode - 6 Amp (Not Shown) 1
701D 3730103 Resistor 8.2K (Not Shown) 1
CONTACTOR PLATE ASSEMBLY
0254549 30electric/35electric/40electric Ref. C
0254597 45electric Ref. C
801 2400045 Fuse 80 Amp (Not Shown) 1
802 7013301 Contactor (Changeover) 1
7013316 Tip Kit for 7013301 Contactor 1
803 7013306 Contactor (Main) 1
7013317 Tip Kit for 7013306 Contactor 1
803A 7013332 Micro Switches Kit for 7013306 Contactor 1
804 7013303 Contactor (By-Pass) 1
7013318 Tip Kit for 7013303 Contactor 1
805 7013302 Contactor (Forward/Reverse) 1
7013319 Tip Kit for 7013302 Contactor 1
806 2400041 Fuse, Buss - 200 Amp 1
807 7013336 Bar, Buss 1
808 Not Serviced Plate, Mounting 1
809 7013314 Board, PC 1
2400005 Fuse, 20Amp 1
7013322 Fuse, 7Amp 1
810 Not Serviced Decal 1
811 7013313 Harness Assembly (See Items 901 to 906 for
Breakdown) 1
812 7013315 Resistor/Bracket Assembly 1
812A 4460224 Connector, Female 1
4460268 Socket 6
FIGURE 7-7. HARNESS COMPONENTS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
