SECTION 5 CYLINDER
FIGURE 5-4. LOWER LIFT CYLINDER ASSEMBLIES - MODELS 35ELECTRIC, 40ELECTRIC AND
45ELECTRIC
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
LOWER LIFT CYLINDER ASSEMBLY
1683013 45electric (Prior to S/N 33090) Ref. 4
1683521 45electric (S/N 33090 to Present) Ref. A/1
1682855 40electric (Prior to S/N 33111) Ref. D/4
1683518 40electric (S/N 33111 to Present) Ref. A/1
1682980 35electric Ref. 4
1 Barrel Weldment Options: 1
45electric
1683014 1683013 Cylinder (Prior to S/N33090)
1683515 1683521 Cylinder (S/N33090 to Present)
40electric
1682856 1682855 Cylinder (Prior to S/N 33111)
1683512 1683518 Cylinder (S/N 33111 to Present)
1682981 35electric
0961726 Bushing, Teflon 2
2 Rod Weldment Options: 1
1683016 45electric
1682858 40electric
1682983 35electric
0961726 Bushing, Teflon 2
3 Retainer Options: 1
1120094 45electric
1120305 40electric
1120305 35electric
4 Piston Options: 1
3480102 45electric
3480113 40electric
3480113 35electric
5 Head Options: 1
1682323 45electric
1682209 40electric
1682209 35electric
6 3300281 Nut, Hex 1
7 Washer Options: 1
Not Required 45electric
4740207 40electric
4740207 35electric
8 Spacer Options: 1
4566432 45electric
4565992 40electric
4566261 35electric
9 Cartridge, Holding Valve Options: 1
40/45electric
4640634 Cartridge, Holding Valve 1
2900770 Seal Kit - 4640634 Valve 1
Not Required 35electric
