3120862 1-11
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-3. TIRE AND WHEEL DRIVE INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
WHEEL DRIVE INSTALLATIONS
0254710 30electric U/L Models Ref. 8
0257551 30electric Non-U/L Models Ref. 1
0254485 35/40electric U/L Models Ref. 8
0257549 35/40electric Non-U/L Models Ref. 1
0254485 n35/n40electric U/L Models Prior to October 1994 Ref. 8
0255111 n35/n40electric U/L Models Oct 1994 to Present Ref. 3
0257548 n35/n40electric Non-U/L Models Ref. 1
0254599 45electric U/L Models Ref. 7
0257550 45electric Non-U/L Models Ref. 1
1 Drive Hub Assembly Options: 1
2780185 30electric (See Figure 1-5 for Breakdown)
2780198 35/40/45electric (See Figure 1-6 for Breakdown)
2780198 n35/n40electric Non-U/L Models (See Figure 1-6
for Breakdown)
2780198 n35/n40electric U/L Models Prior to October 1994
(See Figure 1-6 for Breakdown)
2780206 n35/n40electric U/L Models October 1994 to Pres-
ent (See Figure 1-6 for Breakdown)
2 0920090 Drive Brake Assy (See Figure 1-4 for Breakdown) 2
3 3160186 Drive Motor Assembly 2
2900811 Repair Kit (Includes All Bearings, Brushes, Springs
and Wavy Washer (1 Per Motor) 2
7012546 Field Coil Kit (1 Per Motor) 2
4 3321801 Nut 1/2"-20NF 18
0100011 Loctite #242 A/R
5 4711800 Flatwasher 1/2" Narrow 22
6 0641811 Bolt 1/2"-13NC 4
7 0641608 Bolt 3/8"-16NC x 1" 8
8 4711600 Flatwasher 3/16" Narrow 8
9 4761600 Lockwasher 3/16" 8
10 0630016 Bolt, Wheel Options: A/R
30electric 10
35/40/45electric 12
11 3990053 Sensor, Tach Drive 1
7012609 Boot, Rubber 1
12 4761800 Lockwasher 1/2" 4
13 3790240 O-Ring 2
14 2220273 Fitting, Reducer (S/N 32280 to Present) 2
15 2180819 Vent, Breather (S/N 32280 to Present) 2
TIRE AND WHEEL INSTALLATION OPTIONS -
MODEL 30electric Ref.
0252430 Tire and Wheel Assembly (Foam-Filled) Ref.
0252349 Tire and Wheel Assembly (26x7x20 Non-Marking) Ref. A
101 0252431 Tire and Wheel Assembly (Foam-Filled) (Sold as
an Assembly Only) 4
4520139 Tire, Replacement 4
