JLG 45e Parts Manual - Manual (Page 138)

5-8 3120862
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
8 Spacer Options: 1
40electric & 45electric
4566009 1682867 Cylinder (Prior to March 1995)
4566009 1683337 Cylinder (March 1995 to S/N 29899)
4567177 1683506 Cylinder (S/N 29899 to S/N 33090)
4567177 1683520 Cylinder (S/N 33090 to Present)
4566473 35electric
9 Not Required
10 Cartridge, Holding Options: 1
40electric & 45electric
4640771 Cartridge (Prior to March 1995)
4640936 Cartridge (March 1995 to Present)
2900770 Seal Kit - 4640771 and 4640936 Valves 1
35electric
4640771 Cartridge, Holding Valve 1
2900770 Seal Kit - 4640771 Valve 1
11 Plug Options: 1
2220885 40electric & 45electric
Not Required 35electric (Prior to February 1995)
2220883 35electric (February 1995 to Present)
12 3900170 Setscrew 3/8"-16NC x 3/8" 1
13 3951402 Setscrew 1/4"-20NC x 1/4" 1
14 Kit Ring, Lock 2
15 Kit Seal, Piston 2
16 Kit O-Ring 1
17 Kit Ring, Wear 1
18 Kit O-Ring 1
19 Kit Seal, Rod 1
20 Kit Wiper Rod 1
21 0100011 Loctite #242 A/R
22 0100038 Primer, Locking A/R
23 0100035 Loctite #222 A/R
24 Valve Options: 1
Not Required 40electric & 45electric
4640799 35electric - Cartridge, Needle Valve (Prior to Feb-
ruary 1995)
4640869 35electric - Valve Manual Release (February 1995
to Present)
25 2980121 Lever (February 1995 to Present) 1
26 3430408 Pin, Clevis (February 1995 to Present) 1
27 3450202 Pin, Cotter (February 1995 to Present) 1
28 3440413 Pin, Roll (February 1995 to Present) 1
29 1120459 Cap, Lever (February 1995 to Present) 1
— — — — — — — — — —
FIGURE 5-2. UPPER CYLINDER ASSEMBLIES - MODELS 35ELECTRIC, 40ELECTRIC AND
45ELECTRIC (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
