7-2
3120862
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-1.
ELECTRICAL COMPONENTS AND DIAGRAMS LIST - 30ELECTRIC
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
ELECTRICAL COMPONENTS AND DIAGRAMS LIST -
30ELECTRIC
Ref.
Note: Numbered colored wiring starts with S/N
36544. Items with * indicate electrical drawing
shown in this manual. All other electrical drawings
are available from the JLG Service Department
upon request.
4932845
BATTERY CHARGER CUTOUT ELECTRICAL DIA-
GRAM (AUSTRALIAN SPEC ONLY)
Ref.
A
0254745
BEACON LIGHT ELECTRICAL DIAGRAM
Ref.
A
DRIVE CUTOUT ELECTRICAL
DIAGRAMS
4932682/1282199
Above Elevation (French Spec)
Ref.
—/C
4932683/1282199
Above Elevation (Italian Spec)
Ref.
—/C
3740087
Relay
1
4120027
Base, Relay
1
3740063
Spring, Relay
1
3990001
Diode 3.5
1
4932687
Eight Meter (Dutch/Austrian/German Spec)
Ref.
—
4932686/1282199
Eight Meter (CE Spec)
Ref.
—/—
4932577
Horizontal
Ref.
—
3740087
Relay
1
4120027
Base, Relay
1
3740063
Spring, Relay
1
4921442
Diode Harness
1
4932617
LOW VOLTAGE CUTOUT ELECTRICAL DIAGRAM
Ref.
A
MOTION ALARM ELECTRICAL DIAGRAMS
2901212
Prior to S/N36544
Ref.
—
2901560
S/N 36544 to Present
Ref.
1/A
PLATFORM ELECTRICAL DIAGRAMS
4932674
Prior to S/N 33441)
Ref.
A
4932936
S/N 33441 to S/N36544
Ref.
—
4933002
S/N 36544 to Present
Ref.
B/2
4932927
PLATFORM OVERLOAD ELECTRICAL DIAGRAM
(WITH PRESSURE SWITCH UNDER BASKET)
Ref.
2
2901251
/
1281821
PLATFORM WORKLIGHTS ELECTRICAL DIA-
GRAM (PRIOR TO S/N 36544)
Ref.
B/C
2901561
/
1282857
PLATFORM WORKLIGHTS ELECTRICAL DIA-
GRAM (S/N 36544 TO PRESENT)
Ref.
2/B
