SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
34
0641606
Bolt 3/8"-16NC x 3/4"
2
35
0561173
Block, Boom Rest
1
36
Decal - Manual Descent
1
1701717
Prior to February 1995
1702561
February 1995 to Present
37
0641808
Bolt 1/2"-13NC x 1"
7
LOWER BOOM WELDMENTS
0800866
Prior to August1994
Ref.
—
0801007
August 1994 to Present
Ref.
B/2
101
0961726
Bushing, Teflon
4
4844576
LOWER LINK WELDMENT
Ref.
—
111
0961726
Bushing, Teflon
4
CABLES AND CLAMPS INSTALLATIONS
0254595
Prior to S/N 36648 w/o Numbered Colored Wire
Ref.
D
0258565
S/N 36648 to Present w/ Numbered Colored Wire
Ref.
1
201
Harness - Upper Boom Options (See Section 7 for
Breakdown):
1
4921644
Prior to S/N 36648
4922128
S/N 36648 to Present
202
4921650
Harness-Lower Boom (See Section 7 for Breakdown)
1
203
0561090
Clamp, Block
2
204
3536999
Cover
1
205
1320205
Clamp
2
206
4751400
Flatwasher 1/4"
12
207
3311401
Nut 1/4"-20NC
6
208
3311505
Locknut 5/16"-18NC
2
209
3300151
Nut, Acorn 1/4"-20NC
6
210
0641514
Bolt 5/16"-18NC x 1 3/4"
2
211
4060805
Trim 1/4"
6ft/1.8m
212
4060808
Trim 1/2"
10in/25cm
213
4240099
Tie-Strap
26
214
1320159
Clamp
1
215
0641511
Bolt 5/16"-18NC x 1 3/8"
1
216
4751500
Flatwasher 5/16"
4
217
4060803
Trim 1/16"-1/8"
6in/15cm
218
0100011
Loctite #242 (Not Shown)
A/R
219
1320195
Cover, Clamp
1
220
1320199
Clamp
1
221
0641520
Bolt 5/16"-18NC x 2 1/2"
1
222
3311505
Locknut 5/16"-18NC
1
FIGURE 3-2. BOOMS AND LIMIT SWITCHES INSTALLATION MODEL 35ELECTRIC (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
