3120862 7-5
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
4932935 LIGHTS ELECTRICAL DIAGRAM
4932935 Headlights & Taillights Ref. A/1
4932970 Headlights & Back-up Lights Ref. A/2
4360199 Switch, Toggle SPST 1
3740087 Relay, 48V 50/60 HZ A/R
4120027 Socket, Relay A/R
3740063 Relay, Spring A/R
3990001 Semiconductor, Diode A/R
4360069 Circuit Breaker 1
0257410 LOW BATTERY LIFT INTERRUPT ELECTRICAL
DIAGRAM (UL MODELS) Ref. B/3
0259631 LOW BATTERY LIFT INTERRUPT ELECTRICAL
GRAM DIAGRAM (35electric - UL MODELS) (S/N
47049 TO PRESENT) Ref. A/2
2420049 Gauge, Battery Capacity with Relay 1
3252537 Nameplate - Low Voltage Interrupt 1
4120027 Socket, Relay 1
3740063 Relay, Spring 2
3740087 Relay 48V 50/60 HZ 1
0255522 MANUAL ASCENT ELECTRICAL DIAGRAM (DUTCH
SPEC) Ref. 2
MOTION ALARM ELECTRICAL COMPONENTS
(OPTIONAL)
2901302 35electric Prior to S/N 36648 Ref. A
2901600 35electric S/N 36648 to Present Ref. 1
2901249 40/45electric Prior to S/N 36648 Ref. A
2901601 40/45electric S/N 36648 to Present Ref. 1
PLATFORM ELECTRICAL DIAGRAMS
4932659 Prior to S/N 33441 Ref. C
4932937 S/N 33441 to S/N36648 Ref. —
4932988 S/N 36648 to Present Ref. 2/B
4932882 PLATFORM PROXIMITY SWITCHES ELECTRICAL
DIAGRAM Ref. B/2
3740087 Relay 1
4120027 Base, Relay 1
3740063 Spring, Relay 1
3990001 Diode - 3.5 Amp 1
2901251/1281821 PLATFORM WORKLIGHTS ELECTRICAL DIA-
GRAM (PRIOR TO S/N 36648) Ref. C/C
2901561/1282857 PLATFORM WORKLIGHTS ELECTRICAL DIA-
GRAM (S/N 36648 TO PRESENT)
Ref. 2/B
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
