JLG 45e Parts Manual User Manual
Page 79
3120862
2-31
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
GROUND CONTROL BOX ASSEMBLY
0860917
35electric Euro & Australian Spec Prior to S/N36648
without Numbered Colored Wire
Ref.
5
0861189
35electric Euro Spec S/N36648 to Present with
Numbered Colored Wire
Ref.
4
0861209
35electric Australian Spec S/N36648 to Present
with Numbered Colored Wire
Ref.
4
0860919
40electric & 45electric Euro & Australian Spec Prior
to S/N 36648 without Numbered Colored Wire
Ref.
3
0861191
40electric & 45electric Euro Spec S/N 36648 to
Present without Numbered Colored Wire
Ref.
3
0861210
40electric & 45electric Australian Spec S/N 36648 to
Present without Numbered Colored Wire
Ref.
2
1
Lid Options:
1
3252350
35electric (Prior to S/N 47045)
3252649
35electric (S/N 47045 to Present)
3252351
40electric & 45electric (Prior to S/N 47045)
3252650
40electric & 45electric (S/N 47045 to Present)
2
Seal Options:
50 in./1.3m
3960447
35electric
3960438
40electric & 45electric
3
0630464
Screw #10-24NC x 1/2"
6
4
4740120
Washer, Nylon
6
5
2420106
Voltmeter
1
7012665
Guard, Domed (Optional)
1
6
4360314
Switch, Toggle
6
7
4060802
Guard, Switch
6
8
4740397
Spacer
6
9
4360289
Switch, Emergency Stop (Prior to S/N 47045)
1
7012611
Head, Mushroom
1
7012612
Boot
1
4360475
Switch, Emergency Stop (S/N 47045 to Present)
1
7020175
Cap/E-Stop With Sealing Ring
1
7020176
Contact Block With Mount Collar
1
10
4360347
Switch, Master Key (Select) (Prior to S/N 47045)
1
7012587
Key, Replacement
1
4360474
Switch, Master Key (Select) (S/N 47045 to Present)
1
2860030
Key, Replacement
1
11
Mounting Options:
1
3538001
Plate, Mounting (35electric) (Not Shown)
0860883
Box Weldment (40electric & 45electric)
12
4460425
Connector, Strain Relief
2
13
4460426
Connector, Strain Relief
1
14
3910608
Screw, Round Head #6-32NC x 1/2"
2
15
4760600
Lockwasher #6
2
16
4750600
Flatwasher #6
2
17
3310601
Nut #6-32NC
2
