SECTION 2 TURNTABLE
FIGURE 2-7. SWING DRIVE AND TURNTABLE BEARING INSTALLATIONS - MODELS 40ELECTRIC
AND 45ELECTRIC.
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
SWING DRIVE AND TURNTABLE BEARING INSTAL-
LATION
0253508
40electric
Ref.
3
0253533
n40electric
Ref.
4
0253508
45electric
Ref.
3
1
Turntable Bearing and Rotation Box Assembly
Options:
1
0440203
Production (See Items 101-102 for Breakdown)
0440339
Post Production Service Replacement (See Figure
2-8 for Breakdown)
2
0100019
Loctite
A/R
3
3160182
Swing Motor Assy (See Figure 2-7 for Breakdown)
1
4
0681814
Bolt 1/2"-13NC x 1 3/4" Grade 8
2
5
4740171
Washer, Hardened
2
6
0682026
Bolt 5/8"-11NC x 3 1/4"
18
7
4740393
Washer, Hardened
42
8
Grease, Bearing Options:
A/R
3020027
Grease, Bearing (5 Gallon Bucket) (Prior to S/N
31641)
3020036
Grease, Bearing (S/N 31641 to Present0
9
3020029
Grease, Bearing
A/R
10
Bolt Options:
24
0682028
40electric (Bolt 5/8"-11NC x 3 1/2" Grade 8)
24
0682048
n40electric (Bolt 5/8"-11NC x 6" Grade 8)
24
0682028
45electric (Bolt 5/8"-11NC x 3 1/2" Grade 8)
24
11
Plate, Counterweight Options:
A/R
Not Required
40electric & 45electric
0
4844595
n40electric
1
12
Plate, Spacer Options:
A/R
Not Required
40electric & 45electric
0
3536755
n40electric
1
0440203
TURNTABLE BEARING AND ROTATION BOX ASSEM-
BLY (PRODUCTION)
Ref.
E
101
7012596
Bearing, Turntable
1
102
7012597
Swing Rotation Box Assembly
1
7012654
Seal, Outer - Capped End (1.75 O.D.)
1
7016676
Seal, Outer - Capped End (2.063 O.D.)
1
7012655
Seal, Outer - Motor End
1
