3-16 3120862
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
32 1320195 Cover, Clamp 1
33 1320199 Clamp 1
34 0641520 Bolt 5/16"-18NC x 2 1/2" 1
35 3311505 Locknut 5/16"-18NC 1
BOOM LIMIT SWITCHES INSTALLATIONS
(40ELECTRIC)
0253704 40electric Ref. 5
0254875 45electric Ref. 4
101 4360321 Switch, Limit 2
102 4460428 Connector, Strain Relief 2
103 3311005 Locknut #10-24NC 4
104 Not Used
105 Bolt, Socket Head Options:#10-24NC x 1 1/2" (Prior
to S/N 33795) 2
3900168 Prior to S/N 33795 (#10-24NC x 1 1/2") 2
3900246 S/N 33795 to Present (#10-24NC x 1 3/4") 2
106 Bolt, Socket Head Options: 2
3900097 Prior to S/N 33795 (#10-24NC x 2 1/8") 2
3900104 S/N 33795 to Present (#10-24NC x 2 1/4") 2
107 1060341 Cable, Electrical - 16/2 A/R
40electric 48 ft./17.7m
45electric 58 ft./15m
108 1670832 Cover, Switch Lower (S/N 33795 to Present Only) 1
109 1670833 Cover, Switch Upper (S/N 33795 to Present Only) 1
FIGURE 3-4. LIMIT SWITCHES, CABLES AND CLAMPS INSTALLATION - MODEL 40ELECTRIC AND
45ELECTRIC (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
