Specifications
Multi - Zone Receivers
Specifications CT600.3 CT300.3 CT600.1
Number of Zones 6 Stereo / 12 Mono 3 Stereo / 6 Mono 6 Stereo / 12 Mono
Internal AM / FM Tuner 3 3 1
Power Rating @ 8
W
(4
W stable all Ch driven)
All Zones
55 Watts / Ch
All Zones
55 Watts / Ch
All Zones
55 Watts / Ch
Signal To Noise Ratio 89 dB 89 dB 89 dB
Audio Frequency Response 20 Hz - 20 kHz 20 Hz - 20 kHz 20 Hz - 20 kHz
Audio Source Inputs 9 (RCA) 9 (RCA) 9 (RCA)
Audio Loop Outputs (Buffered) 9 (RCA) 9 (RCA) 9 (RCA)
Audio Buffered Output Impedance 220
W
220
W
220
W
Video Freq. Response - Composite 20 Hz - 10 MHz 20 Hz - 10 MHz 20 Hz - 10 MHz
Video Source Input Impedance 75
W
75
W
75
W
Video Source Inputs 9 Composite 9 Composite 9 Composite
Video Loop Outputs (Buffered) 9 Composite 9 Composite 9 Composite
Video Output Impedance (Buffered) 75
W
75
W
75
W
Dedicated Zone AV Inputs 6 (RCA) 3 (RCA) 6 (RCA)
Zone Line AV Outputs 6 (RCA) 3 (RCA) 6 (RCA)
Source IR Flasher Outputs 9 (1/8” plug) 9 (1/8” plug) 9 (1/8” plug)
IR flasher voltage 5V with 475
W in-series
5V with 475
W in-series
5V with 475
W in-series
Command and Control
IR/RS-232/
Ethernet (pending)
IR/RS-232/
Ethernet (pending)
IR/RS-232/
Ethernet (pending)
IR In 1 (1/8” plug) 1 (1/8” plug) 1 (1/8” plug)
IR Pass 1 (1/8” plug) 1 (1/8” plug) 1 (1/8” plug)
All IR Out 1 (1/8” plug) 1 (1/8” plug) 1 (1/8” plug)
IR Link In 1 (RJ-45) 1 (RJ-45) 1 (RJ-45)
IR Link Out 1 (RJ-45) 1 (RJ-45) 1 (RJ-45)
RS-232 Device Control Yes - triggered using IR Yes - triggered using IR Yes - triggered using IR
Keypad Data Inputs 6 (RJ-45) 3 (RJ-45) 6 (RJ-45)
12 Volt Control / Status Outputs 6 3 6
Common Control Inputs 2 1 2
Common Control Outputs 2 1 2
Whole House Presets 100 100 100
Overall Dimensions Height
(Cutout Dimensions) Width
Depth
7.50” (7.62”)
17.00” (17.12”)
15.50” (16.62”)
7.50” (7.62”)
17.00” (17.12”)
15.50” (16.62”)
7.50” (7.62”)
17.00” (17.12”)
15.50” (16.62”)
Shipping Weight 55 lbs. 50 lbs. 55 lbs.
