41
Splitting a Zone To Mono
Once a zone has been split into mono it has the ability to have a discrete IR Code-Set assigned to it and
therefore the user is given the capability to control volume, mute, and power in the split zone independently.
For more information on Code-Sets, see Page 38. The Installation diagram of a mono zone split for control
is illustrated below. The split mono zone will still share the same source, bass, treble and EQ settings.
Sub-Zoning
In this example, the master bath and master bedroom split a zone into two mono zones. Each mono zone
must listen to the same source, but volume and on/off states are independent via the two keypads. The key-
pads are daisy chained to the same zone control terminal. The CT Receiver must be setup to respond to
the discrete Code-Set for each mono zone. Furthermore, the corresponding Code-Set should be pro-
grammed onto the keypad. Thus, the Master Bath keypad will affect only the Master Bath and the Master
Bed keypad will affect only the Master Bed. When keypads are slaved off of one another, programming
should be done in series order starting with the master keypad, then slave 1, etc. Both keypads may also
have the ability to control both zones together as a suite. The alternative to mono split zones is to assign
the the master bed and master bath to separate independent zones.
