CT Receiver Speaker Connections
Example CT Receiver Six Zone Speaker Connections
Amp channels are 4
W stable.
Zone B
Speakers
Zone A
Speakers
Zone C
Speakers
Zone F
Speakers
Zone
Speaker
Connections
Zone E
Speakers
Zone D
Speakers
Positive
Negative
[R+] Right Positive Speaker Output (Red Wire)
[R-] Right Negative Speaker Output (Green Wire)
[L+] Left Positive Speaker Output (Red Wire)
[L-] Left Negative Speaker Output (Green Wire)
[-] Negative Speaker Input (Green Wire)
[+] Positive Speaker Input (Red Wire)
