Section 1 Basic Printer Functions 1-6
1. 4 Specifications
Subject Specification
Model KIP
7000
Configuration Console
Printing method
Electrophotography
Photoconductor Organic Photoconductive Drum
Print speed 160mm per second (13 D or 7 sheets of A0 per minute)
Print head LED
Resolution 600dpi
Print width
Maximum width 914mm (36 inches)
Minimum width 210mm(cut sheet) / 11inches (Roll Paper)
Print length Maximum length 6m 19.7’ ft (Standard)
24m or unlimited (Optional)
Minimum length 210 or 8.5” mm
NOTE : If the print is longer than 6m, image quality or the reliability
of media feeding systems is not guaranteed
Warm up time Less than 6 minutes (At 23 degrees Centigrade, 60% RH and the
rated voltage/Plain Paper)
First print time 15.5 seconds (A0 or E print from Roll 1)
Fusing method Roll Fuser
Development method Dry type with non-magnetic mono-component toner
Exposure method LED
Charging method Corona
Transfer method Corona
Separation method Corona
Input power 220V - 240V plus 6% or minus 10%, 50/60Hz, 16A
Average power
consumption 230V, 50/60Hz and Dehumidify Heater is ON
Stand by 1.0kwh
Printing 2.6kwh
Acoustic noise Less than 67db (Printing)
Less than 55db (Stand by)
Ozone Smaller than 0.1ppm (Average)
Dimensions 1385mm (Width) x 810mm (Depth) x 1590mm (Height)
( 55” x 32” x 63” ) (without Tray)
Weight Approx. 370kg or 815 lbs
Media (Recommended Media)
Plain Paper US Bond (20lbs)
Tracing Paper US Vellum (20lbs)
Film 4MIL
Environmental condition
for usage (Temperature)
10 to 32 degrees Centigrade
50 to 89 F
(Humidity)
20 to 85% RH
Interface Hi-Speed (LVDS) I/F VIII interface
NOTE 1: The above specifications may change without notice.
NOTE 2:
Media Wrap the media surely to shut out the humidity.
Toner Keep the toner cartridge away from the direct sunlight, and store it
in the condition of 0 to 35 degrees Centigrade and 10 to 85% RH.
