70 Chapter 5 Error Conditions, Problems, and Solutions
Clear Paper Jams
[32]
[34]
[34] Gathering Area Belt Positions
Jam in the Bridge Infeed
1. Open the bridge infeed cover.
2. Remove the jammed paper.
3. Close the bridge infeed cover.
4. Touch STOP to clear the message from the screen.
5. If there is paper in the gathering area, touch START , then touch ADVANCED
> PURGE SET > PURGE SET to clear the set from the machine.
6. Continue the print job.
Jam in the Connecting Bridge
1. Open the connecting bridge cover.
2. Remove the jammed paper. Do not damage or move the belts.
3. Close the connecting bridge cover.
4. Touch STOP to clear the message from the screen.
A Orange Plastic Hand Screw
B Locking Plate
C Trim Stop Guard
