AT-S65 Management Software User’s Guide
87
The Module Diagnostics Menu is shown in Figure 44.
Figure 44. Module Diagnostics Menu
The Module Diagnostics Menu contains the following information about
the line card as a whole:
Hardware Revision/Firmware Revision
The revision level of the line card hardware and firmware.
Line Card Part Number
The line card part number.
Line Card Serial Number
The line card serial number.
Line Card Voltage
The current line card voltage ± 1%.
Line Card Temperature
The current temperature of the line card ± 3º C. To set the maximum
line card temperature, refer to “Configuring the Line Card Temperature
Threshold” on page 34.
Line Card Bias
The bias current of the line card transmitter’s laser ± 10%.
Line Card Transmit Power
The line transmitter’s output power ± 2 dB.
Line Card Receive Power
The line receiver’s input power. (Only values less than -24 dBm are
monitored with ± 2 dB accuracy.)
Module Diagnostics Menu
Hardware Revision REV A
Firmware Revision REV A
Line Card Part Number AT-LX3811/1
Line Card Serial Number A02007A040400002
Line Card Voltage 3.306 V
Line Card Temperature 46.0 Celsius
Line Card Bias 11.82416 mA
Line Card Transmit Power 2.95589089 dBm
Line Card Receive Power -24 dBm
Current Data Rate 623.770 Mbps
SFP Status Online
Return to Line Card Diagnostics Menu ...
