Chapter 4: Monitoring System Performance
52
Displaying System Status Information
The AT-S65 management software provides comprehensive status
information about the operation of the chassis and its components,
including detailed information about the line cards.
To view chassis status information, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is shown in Figure 24.
Figure 24. Module Status and Configuration Menu
The Module Status and Configuration Menu displays basic information
about all the components currently installed in the chassis, including:
ˆ Line cards (items 1 through 8)
ˆ Management board (Ethernet port) (Item 9)
ˆ Main and redundant power supplies (items 10 and 11)
ˆ Chassis fans (items 12 through 14)
The “WDM Side” information coordinates with the Line LEDs, and the
“Port Side” coordinates with the Trib LEDs on the line cards.
For details about the line card information on this menu and how to
display detailed information, refer to Chapter 5, “Working With Line
Module Status and Configuration Menu
Module -------------WDM Side------------------- ----------Port Side----------
Status Tx Rx T_SYN R_SYN MaxRate TX Rx SFP
1: Not Present Unknown
2: Not Present Unknown
3: AT-LX3811/2 MISMATCH
4: Not Present Unknown
5: Not Present Unknown
6: Not Present Unknown
7: AT-LX3811/7 On Offline Offline Off Off OM Offline Offline Out
8: Not Present Unknown
9: MGMT BOARD Off
10: AT-RPSA
11: Not Present Unknown
12: AT-CPU FAN1 On
13: AT-CPU FAN2 On
14: AT-CPU FAN3 On
Return to Main Menu ...
