AT-S65 Management Software User’s Guide
63
Using the System Diagnostics
The AT-S65 management software provides an option to run diagnostic
self-tests on the chassis and line cards. The following section describes
how to run chassis diagnostics. Using this information helps you diagnose
performance problems with the chassis. For information about the line
card diagnostics, refer to “Displaying the Line Card Diagnostics” on
page 86.
To run chassis diagnostics, perform the following procedure:
1. From the Main Menu, select Administration.
The Administration menu is shown in Figure 13 on page 37.
2. From the Administration menu, select Diagnostics and press Enter.
The Diagnostics Menu is shown in Figure 29.
Figure 29. Diagnostics Menu
3. From the Diagnostics Menu, select Chassis Diagnostics and press
Enter.
Diagnostics Menu
Chassis Diagnostics
Line Card Diagnostics
Return to Administration Menu ...
