AT-S65 Management Software User’s Guide
43
The MGMT BOARD menu is shown in Figure 20.
Figure 20. MGMT BOARD (Ethernet Port) Menu
The MGMT BOARD menu shows the current status of the Ethernet
port:
Port
This item always displays “Tx.”
Link
The status of the connection, which can be one of the following:
Offline - The port does not have an active connection.
Online - The port has an active connection.
3. To give the port a name, select Module name and press Enter.
The name can contain up to 20 alphanumeric characters, including
spaces and special characters.
4. Type a name for the module and press Enter.
5. Return to the Main Menu.
9: MGMT BOARD
Port Link
Tx Online
Module name
Return to Module Status and Configuration Menu ...
