Chapter 3: Virtual LANs
56
Creating a Port-Based VLAN
To create a port-based VLAN, do the following procedure:
1. From the main menu on the left side of the page, select Bridge.
The Bridge folder expands.
2. From the Bridge folder, select VLAN.
The VLAN folder expands.
3. From the VLAN folder, select Port-Based VLAN.
The Port-Based VLAN Page is displayed. See Figure 20.
Figure 20. Port-Based VLAN Page
4. To assign a Port-Based VLAN Index, type an index number in the
Index field.
Choose a value between 1 and 64.
5. To assign a name to a VLAN, type a name in the VLAN Name field.
Enter a value of up to 32 characters. For more information on this field,
refer to “VLAN Name” on page 47.
6. To assign ports to the VLAN, click on the port numbers labeled Group
Member.
7. Click Apply.
8. From the main menu on the left side of the page, select Save
Configuration to Flash to permanently save your changes.
