AT-S105 Management Software Web Browser User’s Guide
139
4. In the Group MAC Address field, enter a multicast MAC address.
The range is from 01:00:5E:00:01:00 to 01:00:5E:7F:FF:FF.
5. Assign the MAC address a Group Member (or members) for selecting
the check box below each group member.
Note
Each group member corresponds to a port number. In addition, you
can assign a port a maximum of 256 static multicast addresses per
switch.
6. Click Add.
The Static Multicast Address Table is updated with the new Group
MAC Address.
Note
The Group MAC Address values that you enter on the Static
Multicast Address Table Page are also displayed on the IGMP
Snooping Page. For more information, see “Configuring IGMP
Snooping” on page 118.
7. From the main menu on the left side of the page, select Save
Configuration to Flash to permanently save your changes.
