AT-S105 Management Software Web Browser User’s Guide
173
Figure 54. Port-based Authentication Across Multiple Switches
Port 15 on Switch B:
Switch A
Port 40: 802.1x
Switch B
Supplicants with
802.1x Port Control Setting:
Force-authorized
Port 18 on Switch A:
802.1x Port Control
Setting: Force-authorized
Port Control Setting:
Force-authorized
Ports 10, 14 & 20
on Switch B:
802.1x Port Control
Setting: Auto
802.1x Client software
RADIUS
Authentication
Server
