Appendix A: AT-S105 Management Software Web Browser Default Settings
224
Bridge/Trunk Config/Port Priority
Port Priority 1 1 0-255
Port mode of LACP
member port 100Full-fixed 100Full-fixed -
Bridge/Mirroring
Mirroring Status Disabled Disabled Enabled/Disabled
Mirroring Port port 1 port 1 port 1-26 / port 1-50
Ingress Mirrored Port 26 ports 50 ports -
Egress Mirrored Port 26 ports 50 ports -
Bridge/Static Multicast
VLAN ID none none 1-4093
Port Based VLAN Index none none 1-64
Group MAC Address none none 01:00:5E:00:01:00-01:00:5E:7F:FF:FF
Group Member 26 ports 50 ports -
Static Multicast group
number 256 entries 256 entries -
Bridge/IGMP Snooping
IGMP Snooping Status Disabled Disabled Enabled/Disabled
IGMP Snooping Age-
Out Timer 280 seconds 280 seconds 280 - 420 seconds
Bridge/Bandwidth Control/Storm Control
DLF Disabled Disabled Enabled/Disabled
Broadcast Control
Status Disabled Disabled Enabled/Disabled
Multicast Control Status Disabled Disabled Enabled/Disabled
Threshold Low Low High (2500 pps)
Medium (1000 pps)
Low (500 pps)
Packet size = 1518 Bytes
Table 11. AT-S105 Management Software Default Settings (Continued)
Parameter
AT-FS750/24POE
Default Setting
AT-FS750/48
Default Setting
Specifications
