AT-S105 Management Software Web Browser User’s Guide
225
Bridge/Bandwidth Control/Ingress Rate Limiting
Bandwidth 64Kbps X Rate Limit 64Kbps X Rate Limit -
Rate port 1-24
port 25, 26
port 1-48
port 49, 50
port 1-24 / port 1-48: 1-1562
port 25,26 / port 49, 50; 1-15625
Status Disabled Disabled Enabled/Disabled
Bridge/Bandwidth Control/Egress Rate Limiting
Bandwidth port 1-24:
64Kbps X Rate Limit
port 25, 26
1850Kbps X Rate Limit
port 1-48
64Kbps X Rate Limit
port 49, 50
1850Kbps X Rate Limit
port 1-24 / port 1-48: 1-1562
port 25,26 / port 49, 50; 1-15625
Rate port 1-24
port 25, 26
port 1-48
port 49, 50
port 1-24 / port 1-48: 1-1562
port 25,26; 1-540
/ port 49, 50; 1-718
Status Disabled Disabled Enabled/Disabled
Bridge/VLAN/VLAN Mode
Mode All ports - 802.1Q
Tagged VLAN All ports - 802.1Q
Tagged VLAN 802.1Q Tagged VLAN or
Port-Based VLAN
Bridge/VLAN/Tagged VLAN
VLAN ID 1 1 2- 4093
VLAN Name Default VLAN Default VLAN 0-32 characters (include 0-9 a-z A-Z
~!@#$%^&*()_+{}|:<>?-=[]\;',./ )
Bridge/VLAN/Port-Based VLAN
Index - - 1 - 64
VLAN (Group) Name none none 0-32 characters (include 0-9 a-z A-Z
~!@#$%^&*()_+{}|:<>?-=[]\;',./ )
VLAN group number
(Port-based) 64 entries 64 entries -
Table 11. AT-S105 Management Software Default Settings (Continued)
Parameter
AT-FS750/24POE
Default Setting
AT-FS750/48
Default Setting
Specifications
