AT-S105 Management Software Web Browser User’s Guide
129
4. To set the Bandwidth field, enter a number in the range specified in
Table 4 on page 129 next to the port that you want to change.
You can use the option next to the ALL row to set all of the ports to the
same setting.
5. Click Apply.
6. To enable or disable egress rate filter, select Enable or Disable from
the Status pull-down menu next to the port that you want to change.
The default is Disable. You can use the option next to the ALL row to
set all of the ports to the same setting.
7. Click Apply.
8. From the main menu on the left side of the page, select Save
Configuration to Flash to permanently save your changes.
Table 4. Egress Bandwidth Ranges by Port
Model Ports Bandwidth Range
Default
Value
AT-FS750/24POE 1 -24 64Kbps x (1 - 1562) 1562
25 and 26 1850Kbps x (1 - 540) 540
AT-FS750/48 1 - 48 64Kbps x (1 - 1562) 1562
49 and 50 1850Kbps x (1 - 15625) 15625
