Chapter 10: Bandwidth Control
126
Setting Ingress Rate Limiting
This procedure explains how to set Bandwidth levels and Status for
Ingress Rate Limiting on each port of the AT-FS750/24POE and AT-
FS750/48 switches.
To change the default settings, do the following procedure:
1. From the main menu on the left side of the page, select the Bridge
folder.
The Bridge folder expands.
2. From the Bridge folder, select Bandwidth Control
The Bandwidth Control folder expands.
3. From the Bandwidth Control folder, select Ingress Rate Filtering.
The Ingress Rate Limiting page is displayed. A partial view is shown in
Figure 40.
Figure 40. Ingress Rate Limiting Page
